PART NO. 规格/编码 |
ITEM NO. 品名型号 |
尺寸DIMENSIONS(mm) |
|||||
|
Φd 2 |
B |
L |
ΦD |
Φd |
E |
||
|
FC70M20 |
FC70-20 |
21 |
30 |
72 |
15 |
11 |
21 |
|
FC95M8 |
FC95-8 |
8.5 |
25 |
56 |
17 |
13.1 |
25 |
|
FC95M10 |
FC95-10 |
10.5 |
25 |
60 |
|||
|
FC95M12 |
FC95-12 |
13 |
25 |
62 |
|||
|
FC95M14 |
FC95-14 |
15 |
25 |
66.5 |
|||
|
FC95M16 |
FC95-16 |
17 |
25 |
70 |
|||
|
FC95M20 |
FC95-20 |
21 |
30 |
76 |
|||
|
FC120M8 |
FC120-8 |
8.5 |
28 |
64 |
19 |
14.5 |
26 |
|
FC120M10 |
FC120-10 |
10.5 |
28 |
64 |
|||
|
FC120M12 |
FC120-12 |
13 |
28 |
66 |
|||
|
FC120M14 |
FC120-14 |
15 |
28 |
69.5 |
|||
|
FC120M16 |
FC120-16 |
17 |
28 |
72 |
|||
|
FC150M10 |
FC150-10 |
10.5 |
30 |
71 |
21 |
16.2 |
30 |
|
FC150M12 |
FC150-12 |
13 |
30 |
73 |
|||
|
FC150M14 |
FC150-14 |
15 |
30 |
73 |
|||
|
FC150M16 |
FC150-16 |
17 |
30 |
75 |
|||
|
FC185M12 |
FC185-12 |
13 |
33.5 |
81 |
23 |
18 |
32 |
|
FC185M14 |
FC185-14 |
15 |
33.5 |
85 |
|||
|
FC185M16 |
FC185-16 |
17 |
33.5 |
87 |
|||
|
FC185M20 |
FC185-20 |
21 |
33.5 |
91 |
|||
|
FC240M10 |
FC240-10 |
10.5 |
38 |
93.5 |
26 |
20.6 |
35 |
|
FC240M12 |
FC240-12 |
13 |
38 |
93.5 |
|||
|
FC240M14 |
FC240-14 |
15 |
38 |
93.5 |
|||
|
FC240M16 |
FC240-16 |
17 |
38 |
93.5 |
|||
|
FC240M20 |
FC240-20 |
21 |
38 |
93.5 |
|||
|
FC300M12 |
FC300-12 |
13 |
41 |
96 |
28 |
23 |
44 |
|
FC300M14 |
FC300-14 |
15 |
41 |
102 |
|||
|
FC300M16 |
FC300-16 |
17 |
41 |
102 |
|||
|
FC300M20 |
FC300-20 |
21 |
41 |
106 |
|||
|
FC400M12 |
FC400-12 |
13 |
46.5 |
115 |
32 |
26 |
44 |
|
FC400M14 |
FC400-14 |
15 |
46.5 |
115 |
|||
|
FC400M16 |
FC400-16 |
17 |
46.5 |
115 |
|||
|
FC400M20 |
FC400-20 |
21 |
46.5 |
118 |
|||
|
|
|||||||
|
PART NO. 规格/编码 |
ITEM NO. 品名型号 |
尺寸DIMENSIONS(mm) |
|||||
|
Φd 2 |
B |
L |
ΦD |
Φd |
E |
||
|
S-TL10M6 |
S-TL10-6 |
6.4 |
11.9 |
35 |
6.8 |
4.7 |
18 |
|
S-TL10M8 |
S-TL10-8 |
8.3 |
15 |
38 |
|||
|
S-TL16M6 |
S-TL16-6 |
6.4 |
11.9 |
39 |
7.8 |
5.6 |
21.5 |
|
S-TL16M8 |
S-TL16-8 |
8.3 |
15 |
41.5 |
|||
|
S-TL25M8 |
S-TL25-8 |
8.3 |
15 |
50 |
9.4 |
7.1 |
29 |
|
S-TL25M10 |
S-TL25-10 |
10.5 |
18 |
55 |
|||
|
S-TL35M8 |
S-TL35-8 |
8.3 |
16.5 |
53 |
11.3 |
8.7 |
31 |
|
S-TL35M10 |
S-TL35-10 |
10.5 |
19 |
57 |
|||
|
S-TL50M10 |
S-TL50-10 |
10.5 |
20 |
63 |
12.6 |
9.8 |
35 |
|
S-TL50M12 |
S-TL50-12 |
13 |
21 |
67 |
|||
|
S-TL70M10 |
S-TL70-10 |
10.5 |
21.5 |
69 |
14.7 |
11.5 |
39 |
|
S-TL70M12 |
S-TL70-12 |
13.2 |
21.5 |
71 |
|||
|
S-TL95M12 |
S-TL95-12 |
13 |
24.7 |
79 |
16.9 |
13.5 |
46 |
|
S-TL95M14 |
S-TL95-14 |
14.5 |
24.7 |
83 |
|||
|
S-TL95M16 |
S-TL95-16 |
16.5 |
27 |
86 |
|||
|
S-TL120M12 |
S-TL120-12 |
13 |
28.9 |
87 |
19.9 |
15.6 |
51 |
|
S-TL120M14 |
S-TL120-14 |
14.5 |
28.9 |
91 |
|||
|
S-TL120M16 |
S-TL120-16 |
16.5 |
28.9 |
95 |
52 |
||
|
S-TL150M12 |
S-TL150-12 |
13 |
30.4 |
99 |
20.9 |
16.5 |
56 |
|
S-TL150M14 |
S-TL150-14 |
14.5 |
30.4 |
103 |
|||
|
S-TL150M16 |
S-TL150-16 |
16.5 |
30.4 |
103 |
|||
|
S-TL185M12 |
S-TL185-12 |
13 |
34 |
108 |
23.7 |
18.8 |
62 |
|
S-TL185M14 |
S-TL185-14 |
14.5 |
34 |
112 |
|||
|
S-TL185M16 |
S-TL185-16 |
16.5 |
34 |
113 |
|||
|
S-TL240M12 |
S-TL240-12 |
13 |
38.4 |
114 |
26.2 |
21.2 |
66 |
|
S-TL240M14 |
S-TL240-14 |
14.5 |
38.4 |
118 |
|||
|
S-TL240M16 |
S-TL240-16 |
16.5 |
38.4 |
119 |
|||
|
S-TL300M14 |
S-TL300-14 |
14.5 |
41.7 |
132 |
28.6 |
23.4 |
75 |
|
S-TL300M16 |
S-TL300-16 |
16.5 |
41.7 |
132 |
|||
|
S-TL400M16 |
S-TL400-16 |
16.5 |
47.8 |
140 |
32.8 |
26.8 |
79 |
|
S-TL500M16 |
S-TL500-16 |
16.5 |
54.8 |
143 |
38.4 |
29.8 |
78 |
