PART NO. 规格/编码 |
ITEM NO. 品名型号 |
尺寸DIMENSIONS(mm) |
|||||
|
Φd 2 |
B |
L |
ΦD |
Φd |
E |
||
|
GCL1.5M3 |
GCL1.5-3 |
3.2 |
8 |
21 |
3.7 |
1.8 |
11 |
|
GCL1.5M4 |
GCL1.5-4 |
4.3 |
8 |
22 |
|||
|
GCL1.5M5 |
GCL1.5-5 |
5.3 |
10 |
24 |
12 |
||
|
GCL1.5M6 |
GCL1.5-6 |
6.5 |
10 |
25 |
|||
|
GCL2.5M3 |
GCL2.5-3 |
3.2 |
8 |
22 |
3.9 |
2.3 |
12 |
|
GCL2.5M4 |
GCL2.5-4 |
4.3 |
8 |
23 |
|||
|
GCL2.5M5 |
GCL2.5-5 |
5.3 |
10 |
25 |
|||
|
GCL2.5M6 |
GCL2.5-6 |
6.5 |
10 |
25 |
|||
|
GCL2.5M8 |
GCL2.5-8 |
8.3 |
12.5 |
27.5 |
4.3 |
||
|
GCL4M4 |
GCL4-4 |
4.3 |
10 |
26 |
4.7 |
3 |
13 |
|
GCL4M5 |
GCL4-5 |
5.3 |
10 |
27 |
|||
|
GCL4M6 |
GCL4-6 |
6.5 |
10 |
28 |
|||
|
GCL4M8 |
GCL4-8 |
8.3 |
12.5 |
29 |
|||
|
GCL6M4 |
GCL6-4 |
4.3 |
10 |
33.6 |
5.9 |
4 |
18.5 |
|
GCL6M5 |
GCL6-5 |
5.3 |
10 |
33.6 |
|||
|
GCL6M6 |
GCL6-6 |
6.5 |
11 |
33.6 |
|||
|
GCL6M8 |
GCL6-8 |
8.3 |
12.5 |
36.3 |
|||
|
GCL6M10 |
GCL6-10 |
10.3 |
15 |
37.3 |
6.2 |
||
|
GCL10M5 |
GCL10-5 |
5.3 |
11 |
39 |
6.6 |
4.5 |
22 |
|
GCL10M6 |
GCL10-6 |
6.5 |
11 |
39 |
|||
|
GCL10M8 |
GCL10-8 |
8.3 |
12.5 |
39 |
|||
|
GCL10M10 |
GCL10-10 |
10.3 |
16 |
43.1 |
6.9 |
||
|
GCL10M12 |
GCL10-12 |
12.7 |
18 |
43.1 |
21 |
||
|
GCL16M5 |
GCL16-5 |
5.3 |
11 |
39.7 |
7.5 |
5.5 |
23 |
|
GCL16M6 |
GCL16-6 |
6.5 |
11 |
39.7 |
|||
|
GCL16M8 |
GCL16-8 |
8.3 |
12.5 |
39.7 |
22 |
||
|
GCL16M10 |
GCL16-10 |
10.3 |
16 |
44.9 |
23 |
||
|
GCL16M12 |
GCL16-12 |
12.7 |
18 |
44.9 |
8.1 |
22 |
|
|
GCL25M5 |
GCL25-5 |
5.3 |
13 |
47.2 |
9.1 |
6.7 |
28 |
|
GCL25M6 |
GCL25-6 |
6.5 |
13 |
47.2 |
|||
|
GCL25M8 |
GCL25-8 |
8.3 |
13 |
47.2 |
|||
|
GCL25M10 |
GCL25-10 |
10.3 |
16 |
51.9 |
29 |
||
|
GCL25M12 |
GCL25-12 |
12.7 |
18 |
51.9 |
28 |
||
|
GCL25M14 |
GCL25-14 |
14.8 |
20 |
53.9 |
|||
|
GCL35M5 |
GCL35-5 |
5.3 |
16 |
52.6 |
11 |
8.6 |
31 |
|
GCL35M6 |
GCL35-6 |
6.5 |
16 |
52.6 |
|||
|
GCL35M8 |
GCL35-8 |
8.3 |
16 |
52.6 |
|||
|
GCL35M10 |
GCL35-10 |
10.3 |
17 |
56.5 |
|||
|
GCL35M12 |
GCL35-12 |
12.7 |
18 |
56.5 |
|||
|
GCL35M14 |
GCL35-14 |
14.8 |
20 |
58.5 |
|||
|
GCL35M16 |
GCL35-16 |
16.5 |
23 |
60.5 |
|||
|
GCL50M5 |
GCL50-5 |
5.3 |
18 |
56 |
12.4 |
9.5 |
32 |
|
GCL50M6 |
GCL50-6 |
6.5 |
18 |
56 |
|||
|
GCL50M8 |
GCL50-8 |
8.3 |
18 |
56 |
|||
|
GCL50M10 |
GCL50-10 |
10.3 |
18 |
59 |
|||
|
PART NO. 规格/编码 |
ITEM NO. 品名型号 |
尺寸DIMENSIONS(mm) |
|||||
|
Φd 2 |
B |
L |
ΦD |
Φd |
E |
||
|
GCL50M12 |
GCL50-12 |
12.7 |
19 |
59 |
12.4 |
9.5 |
32 |
|
GCL50M14 |
GCL50-14 |
14.8 |
21 |
67.8 |
34 |
||
|
GCL50M16 |
GCL50-16 |
16.5 |
23 |
67.8 |
|||
|
GCL70M5 |
GCL70-5 |
5.3 |
22 |
67.4 |
15 |
12 |
36.5 |
|
GCL70M6 |
GCL70-6 |
6.3 |
22 |
67.4 |
|||
|
GCL70M8 |
GCL70-8 |
8.3 |
22 |
67.4 |
|||
|
GCL70M10 |
GCL70-10 |
10.3 |
22 |
67.4 |
|||
|
GCL70M12 |
GCL70-12 |
12.7 |
22 |
67.4 |
|||
|
GCL70M14 |
GCL70-14 |
14.8 |
22 |
70 |
|||
|
GCL70M16 |
GCL70-16 |
16.5 |
24 |
70 |
35 |
||
|
GCL95M8 |
GCL95-8 |
8.3 |
25 |
69.7 |
17 |
13.4 |
37.5 |
|
GCL95M10 |
GCL95-10 |
10.3 |
25 |
69.7 |
|||
|
GCL95M12 |
GCL95-12 |
12.7 |
25 |
69.7 |
|||
|
GCL95M14 |
GCL95-14 |
14.8 |
25 |
73.3 |
|||
|
GCL95M16 |
GCL95-16 |
16.5 |
25 |
73.3 |
|||
|
GCL95M20 |
GCL95-20 |
20.9 |
28 |
73.3 |
34.5 |
||
|
GCL120M8 |
GCL120-8 |
8.3 |
27.5 |
75 |
19 |
15 |
38 |
|
GCL120M10 |
GCL120-10 |
10.3 |
27.5 |
75 |
|||
|
GCL120M12 |
GCL120-12 |
12.7 |
27.5 |
75 |
|||
|
GCL120M14 |
GCL120-14 |
14.8 |
27.5 |
79 |
|||
|
GCL120M16 |
GCL120-16 |
16.5 |
27.5 |
79 |
|||
|
GCL120M20 |
GCL120-20 |
20.9 |
27.5 |
79 |
|||
|
GCL150M10 |
GCL150-10 |
10.3 |
30.5 |
82 |
21.2 |
16.5 |
42 |
|
GCL150M12 |
GCL150-12 |
12.7 |
30.5 |
82 |
|||
|
GCL150M14 |
GCL150-14 |
14.8 |
30.5 |
82 |
|||
|
GCL150M16 |
GCL150-16 |
16.5 |
30.5 |
86.4 |
|||
|
GCL150M20 |
GCL150-20 |
20.9 |
30.5 |
86.4 |
|||
|
GCL185M10 |
GCL185-10 |
10.3 |
34 |
88 |
23 |
19 |
45 |
|
GCL185M12 |
GCL185-12 |
12.7 |
34 |
88 |
|||
|
GCL185M14 |
GCL185-14 |
14.8 |
34 |
88 |
|||
|
GCL185M16 |
GCL185-16 |
16.5 |
34 |
91.2 |
|||
|
GCL185M20 |
GCL185-20 |
20.9 |
34 |
91.2 |
|||
|
GCL240M10 |
GCL240-10 |
10.3 |
38.6 |
106.4 |
26.5 |
21 |
53 |
|
GCL240M12 |
GCL240-12 |
12.7 |
38.6 |
106.4 |
|||
|
GCL240M14 |
GCL240-14 |
14.8 |
38.6 |
106.4 |
|||
|
GCL240M16 |
GCL240-16 |
16.5 |
38.6 |
106.4 |
|||
|
GCL240M20 |
GCL240-20 |
20.9 |
38.6 |
106.4 |
|||
|
GCL300M12 |
GCL300-12 |
12.7 |
43.8 |
113 |
30 |
24.5 |
57 |
|
GCL300M14 |
GCL300-14 |
14.8 |
43.8 |
113 |
|||
|
GCL300M16 |
GCL300-16 |
16.5 |
43.8 |
113 |
|||
|
GCL300M20 |
GCL300-20 |
20.9 |
43.8 |
113 |
|||
|
GCL400M12 |
GCL400-12 |
12.7 |
50 |
119 |
35 |
27 |
59 |
|
GCL400M14 |
GCL400-14 |
14.8 |
50 |
119 |
|||
|
GCL400M16 |
GCL400-16 |
16.5 |
50 |
119 |
|||
|
GCL400M20 |
GCL400-20 |
20.9 |
50 |
119 |
|||
